Umugqa Wokukhiqiza I-PP/PE/PA6 Cold Push Plate Crawler --Ukuthuthukiswa Kokubumba Amapuleti Aqinile Okunika Amandla Ngobuchwepheshe Bokusunduza Okubandayo Obusezingeni Eliphansi

Njengoba imboni yokucubungula amapuleti amakhulu epulasitiki iphishekela ukucindezeleka okuphansi kwangaphakathi, ukuba flat okuphezulu kanye nokulahlekelwa kwezinto eziphansi, inqubo yokukhipha ibhodi elibandayo lokushisa eliphansi isibe yisisombululo esithandwayo sokukhiqizwa kwepuleti eliqinile/eliqinile, ngenxa yezinzuzo zalo zokuguquguquka okuphansi, ubuso obubushelelezi kanye nokuhambisana nezinto zokusetshenziswa ezahlukahlukene njenge-PP, PE kanye ne-PA6 nylon. ukubunjwa kwe-extrusion Ngokusungula ubuchwepheshe obusha, i-JWELL ihlanganisa ngokujulile i-plasticization ene-screw eyodwa yokushisa okuphansi, ukwakheka kwe-tempering, i-servo crawler traction kanye nezinqubo zokusika eziqondile, okwenza kube nokukhiqizwa okuqhubekayo nokuzinzile kwemishayo yepulasitiki ephelele kusukela ku-Φ5 kuya ku-300mm. Amapharamitha anjengejubane lokudonsa kanye nobude bokusika angalungiswa kalula ku-inthanethi, okunciphisa kakhulu ukulahleka kwesikhathi sokungasebenzi kanye nokungcola kwezinto zokusetshenziswa okubangelwa ukushintsha kwezinto kanye nemininingwane.

Lolu hlelo lwezinto ezibonakalayo lufinyelele ukumbozwa okugcwele okusabalala emikhakheni eyisisekelo yokuphila kuya ezimbonini ezisafufusa, ludlala indima engenakuphindwa kuzo zonke izixhumanisi zokukhiqiza kwezimboni kanye nokuphila kwansuku zonke.

Uhlelo Lokukhipha Ukushisa Okuphansi Olusebenza Kakhulu

I-extruder ekhethekile ye-JWS50/28 ene-screw eyodwa ifakwe isakhiwo sesikulufo esenziwe ngokwezifiso senqubo yokusunduza ebandayo, esilawula ngokunembile ukwenziwa kwepulasitiki okuphansi kwezinga lokushisa I-PP/PE/PA6 ukugwema ukuphuzi kwe-nylon okubangelwa ukuwohloka kokushisa okuphezulu, okuletha umphumela wokukhipha ozinzile futhi ofanayo.

Ukulawula Izinga Lokushisa kanye nomthamo wokukhiqiza: Ukulawula izinga lokushisa okubili (ukushisa kwe-ceramic okunezindawo ezine okungu-16kW + ukupholisa ifeni), isikulufu sensimbi ye-alloy (≥HV740) kanye nebharele elicwengekileyo (≥HV940) elilingana kahle liqinisekisa ukulawula okuqinile kwebanga lokuncibilika futhi linciphisa ukucindezeleka kwangaphakathi. Umthamo u-15-25kg/h webhodi elibandayo elingu-650mm.

Inqubo Yokulungisa Nokubumba Ngokunembile

Ipuleti lokuthambisa elikhethekile elinokulawula izinga lokushisa okunembile livumelana nokwakheka kwamabhodi obukhulu be-PP/PE/PA6 okushisa okuphansi ukuze kube nobukhulu obuzinzile kanye nokuba yisicaba okuphezulu. Amapuleti okusetha: 700×850×70mm (45# steel) kanye ne-1700×850×70mm (aluminium), ~4-zone heating, matching i-extruder okukhiphayo; izikhunta ezinezimbobo eziningi (16/12/10/6/4) zisekela imigoqo ye-Φ5-300mm enesivinini sokudonswa esilungisekayo ngesikhathi sangempela.

Ukukhiqizwa Okuqhubekayo Okuvaliwe: Kuqaphela ngokugcwele ukusebenza okuqhubekayo kwenqubo yonke "yokukhipha → ukwakheka kokushisa → ukudonsa → ukusika".

Uhlelo Lokudlulisa I-Dual Crawler Servo Traction

Ukubopha Nokudlulisa: Kwenzelwe amabhodi aqinile acindezelwayo abandayo. Ama-servo drive azimele aphezulu/aphansi (i-Innovance 0.85kW ngayinye); ukubopha okuguquguqukayo ngamabhulokhi angagugi e-silicone (afakwe insimbi) kuvimbela ukuklwebheka. Ukubopha komoya okunokucindezela okulungisekayo (i-valve + gauge) kufaneleka ngobukhulu obuhlukahlukene bebha yokudlulisa okuzinzile.

Uhlaka kanye nesivinini: Uhlaka oluphakamisa isikulufu; ukuphakama okuphakathi okuphansi kungu-1050mm, ukuvula kungu-150mm, kuyahambisana nemigoqo engu-Φ5-300mm. Isivinini esiphezulu ngu-60mm/min, ukulawula okubili (isikrini sokuthinta/ikhabhinethi), okuxhunywe nesikhiphi.

Uhlelo Lokuphakela Olusizayo

I-hot air dryer engu-100kg iqinisekisa ukuthi umswakama uhlangabezana nezindinganiso; i-vacuum loader engu-100kg/h ivumela ukuphakelwa okuqhubekayo okuzenzakalelayo ngokungenelela okuncishisiwe ngesandla. Idizayini ehlanganisiwe ehlanganisiwe enokusetshenziswa kwamandla aphansi nomsindo ukuze kube nendawo engcono yokusebenza.

Iyunithi Yokusika Eqondile Nokumisa Okuzenzakalelayo

Ukusika Ngokunembile Nokumisa Ngokuzenzakalelayo: I-Servo encoder iqinisekisa iphutha lobude bokusika ngaphakathi kwe-±1mm; I-VFD-controlled saw motor enetafula lokusika eliphakamisa izikulufo isekela amabhodi afinyelela ku-150mm ubukhulu, enethreyi ye-chip. Amabhodi okusika athunyelwa ngokuzenzakalelayo ku-stacking rack ehlanganisiwe, kunciphisa ukuphathwa ngesandla, kukhulisa ukuzenzekela kanye nokonga abasebenzi.
